Fuel Cell Blower BNHP-35

The Fuel Cell Blower BNHP-35 series enables more efficient fuel cell operations and cost-effective solutions for our customers.

Features

• Partial Emission Centrifugal
• Hermetic Design – no dynamic seals
• Aluminum Housings
• Brushless DC Motor / 250-450V DC
• Liquid Cooled Motor / Bearings / Controller
• High-Speed Ceramic Ball Bearings
• Integrated Controllers (Sensor/Sensorless)
• Variable Speed to 40,000 RPM for wide-range performance
• Weight 4.5 kg (9.9 lb)
• Successfully Passed Environmental Testing

Designation     [mm]     [in]

     A                      290       11.4

     B                      156         6.1
